L × W × H (Overall)
|
78 x 28 x 44 Inches
|
Wheel Base
|
54 Inches
|
Ground Clearance
|
4.33 Inches
|
Seat Height
|
27 Inches
|
Net Weight
|
224 LBS
|
Gross Weight
|
233 LBS
|
Engine type
|
1P39QMB 4STROKE
|
Bore×Stroke (mm)
|
39×41.5
|
Displacement (ml)
|
49.6
|
Compression Ratio
|
10.4:1
|
Max Torque
|
3.0 / 4000 ± 500 n.m (r / min)
|
Starting
|
Electric and Kick
|
Ignition
|
CDI
|
Transmission
|
CVT
|
Carburetor
|
PD19J
|
Fuel Tank
|
1.3 Gallon
|
Tire (Front) | Rim
|
120/70 -12 | 2.5 x 12 Alloy Rim
|
Tire (Rear) | Rim
|
120/70 -12 | 2.5 x 12 Alloy Rim
|
Front Brake
|
Hydraulic Disc
|
Rear Brake
|
Drum
|
Max Speed
|
31 mph
|
|
|
|
