SPECIFICATIONS

MC-81

CONFIGURE

Colors available

Red,Blue,Yellow,Black,Silver

Decals(Y/N)

Y

Tool kit(Y/N)

Y

Remote start(Y/N)

N

Remote engine stop(Y/N)

Y

Remote alarm(Y/N)

N

Speed limiter(Y/N)

N

Assembly required

Battery,Mirror

ENGINE INFO

Engine type

Four-stroke,single-cylinder,CVT

Engine brand

Honling

Displacement

175.6CC

Cooling

Air cooled

Max horsepower

6.85kw at 5500r/min

Max torque

10.92Nm at 4500r/min

Bore*stroke

62.2mm×57.8mm

Max speed

85km/h

Climbing ability

12°

Ignition

C.D.I

Starting system

Electric starter/kick starter

Battery

12V 7Ah

Carburetor brand

HONLING PD24J

Engine oil

SE 15W-40

Gear oil

SF 85W-90

CHASSIS ETC

Clutch

CVT-Automatic

Transmission

Automatic

Driveline

V-belt

Driving wheel

Rear wheel drive

Suspension,front/rear

Front rear double suspension

Brakes,front/rear

Front disc brake,Rear drum brake

Brake operation

Front rear hand brake

Tires,front/rear

 Front:130/60-12. Rear:130/60-13

Fuel capacity/type

6.0L

Weight,G.W./N.W.

128/108kg

Max load

260kg

DIMENSIONS

Wheelbase

1390mm

OA  L*W*H

2150×740×1190mm

Height to seat

758mm

Min ground clearance

160mm

Carton size

CBU:1960×570×1200mm/SKD:1890×570×870mm

Shipping info

24pcs/20gp,50pcs/40gp,75pcs or 47pc(CBU)/40HQ
