125cc ATV
ROKETA
ATV-67
Colors available
|
Red
Blue
Orange
Black |
Decals
|
|
Tool kit
|
|
Speed limiter
|
|
Assembly
required
|
handle bar and wheels
|
|
ENGINE
|
Engine
|
Chain |
Displacement
|
125cc |
Cooling
|
Oil cooled |
Max horsepower
|
7.9hp / 7000rpm |
Max torque
|
8.6n.m / 5500rpm |
Bore*stroke
|
2.06 * 2.24 inches |
Max speed
|
40.4 mph |
Climbing
ability
|
17 degree |
Ignition
|
C.D.I |
Starting
system
|
Electric / kick |
Battery
|
12V5Ah |
Carburetor
|
PZ25 |
Engine oil
|
SAE15W / 40SF |
CHASSIS
|
Clutch
|
Manual |
Transmission
|
4 speed |
Driveline
|
Chain-drive |
Driving wheel
|
Rear wheel drive |
Suspension, front
/ rear
|
Double a- single a-arm |
| Brakes front /
rear ： |
Disc / disc |
Brake
operation
|
Hand + foot |
Tires front /
rear
|
19 * 6-10 / 18 * 6.50-8 |
Fuel capacity
|
0.8 gal |
Weight,G.W./N.W
|
313. 264.6 lbs |
Max load
|
264.6lbs |
DIMENSIONS
|
Wheelbase
|
41.1 inches |
OA L*W*H
|
59.1 * 41.3 * 36.2 inches |
Height to
seat
|
25.6 inches |
Min ground
clearance
|
3.9 inches |
Carton size
|
52.8 * 6 * 28 inches |
|
|
