| Decals (Y/N) ：
|
Y |
| Tool kit (Y/N) ：
|
Y |
| Speed limiter (Y/N) ：
|
Y |
| Assembly required ：
|
* |
|
|
| ENGINE INFO ： |
| Engine type ：
|
3cylinder, 4stroke
|
| Displacement ：
|
800cc |
| Cooling ：
|
Water-cooled |
| Max horsepowe ：
|
35.2hp /5500r/min |
| Max torque ：
|
57/2500-3000N.m/r/min |
| Bore*stroke ：
|
2.7*2.83inches |
| Max speed ：
|
62.1mile/h |
| Climbing ability ：
|
55degree |
| Ignition ：
|
C.D.I |
| Starting system ：
|
Electric |
| Battery ：
|
12V/32Ah |
| Carburetor
|
Fuel Injected
|
| Engine oil ：
|
SAE 15W40SF |
| Gear oil ：
|
85W/40 |
|
|
| CHASSIS ETC ： |
| Clutch ：
|
Foot |
| Transmission ：
|
4-speed+reverse |
| Driveline ：
|
Shaft-drive |
| Driving wheel ：
|
Rear wheel drive |
| Suspension,front/rear ：
|
Double arm-swing/ independent
suspension |
| Brakes,front/rear ：
|
Disc/disc |
| Brake operation ：
|
Hand +foot |
| Tires,front/rear ：
|
* |
| Fuel capacity/type ：
|
5.3gal |
| Weight,G.W./N.W ：
|
1036.2/ 948lbs |
| Max load ：
|
551.2lbs |
| DIMENSIONS ： |
| Wheelbase ：
|
87.4inches |
| OA L*W*H ：
|
134.3*66.9*57.9inches |
| Height to seat ：
|
21.7inches |
| Min ground clearance ：
|
8.5inches |
| Carton size ：
|
116.1*57.9*33.9inches |
| Shipping info ：
|
6pcs/ 20FT ,16pcs/40HQ |
|
