| Dimension (LxWxH) |
2100x1210x1200mm |
| Wheelbase |
1320mm |
| Tread(front) |
920mm |
| Tread(rear) |
935mm |
| Ground clearance |
280mm |
| Seat height |
920mm |
| Dry weight |
320kgs |
| Gross Weight |
345kgs |
| Fuel tank |
13L |
| Max speed |
78km/h |
| Brake system front/rear |
Disk/Disk |
| Gearshift mode |
Automatic clutch, five speed,
one neutral with inside reverse
gear |
| Transmission mode |
Shaft |
| Drive system |
4WD-2WD |
| Tire front |
25x8-12&24x8-12 |
| Tire rear |
25x10-12&24x9-11 |
| Cargo front |
66lbs(30kg) |
| Cargo rear |
133lbs(60kg) |
| Tow weight limit |
3376N(385kgf/850lbs) |
| Tongue weight |
137N(14kgf/30bs) |
| Engine |
| Engine model |
179F |
| Efficient Capacity |
359ml |
| Engine type |
4-stroke, Single-Cylinder |
| Cooling system |
Air-cooled + Oil-cooled7 |
| Rated power and rotate speed |
13.5kw/5500rpm |
| Max torque and rotate speed |
24N.m/4000rpm |
|
Economical oil consumption (L/100km) |
<=5 |
| Electrical |
| Battery |
12V-14Ah |
| Starting system |
Electric/Hand-pull |
| Ignition |
DCDI |
|
