ATV-23
150cc
| ENGINE |
||
| Single cylinder, 150cc ,4-stroke, air-cooled | Displacement :149.5cc | |
| MAX POWER (KW/RPM):7.0Kw/7000(r/min) | Max Torque (N.m/r/min):8.5N.m/6000r/min | |
| Cylinder Diameter*Journey(mm):57.4��57.8 | Engine Oil : 0.93L | |
| Lubrication: Press splash | Compression ratio : 9.1:1 | |
| STARTING |
||
| Electric
start / Kick start |
||
| DEMINSIONS |
||
| L67 x
W36 x H41" |
Wheel Base :1090mm | |
| Dry Weight :140kg | Seat height :760mm | |
| Mini Turning radius : 2400mm | Loading Capacity : 130kg | |
| TIRES |
||
| Front : 19 x 7x 8 | Rear : 18x9.5-8 | |
| TRANSMISSION |
||
| Automatic
CVT |
Chain
Drive |
|
| ELECTRIC |
||
| 12V 9ah |
Ignition:
CDI |
|
| BRAKES |
||
| Front
: Drumb |
Rear :
Disk |
|
| Parking trig: mechanical lock | ||
| SUSPENSION |
||
| Front: double a-arm | Rear : Mono-shock, hanging:integral | |
| FUEL |
||
| Unleaded
Gasoline |
Tank Capacity : 6.6L | |
| 40 Ft. Container 64 Units |
