DIMENTIONS
|
|
(L
x W x H):1970mm x 1050mm x
1150mm |
|
Distance
between axles:1260mm |
Distance
between axles:1260mm |
|
Distance
between front wheels:860mm |
Distance
between rear wheels:840mm |
|
Digital
& Analog Gauges |
Ground
clearance:150mm |
|
Proper
Mass of Empty Vehicle:240kg |
Gross
weight:277KG |
|
Rear
Wheel:22 x
10-10,50Kpa |
Front
Wheel:22 x
7-10,50Kpa |
|
|
|
ENGINE
|
|
Type
of Engine:172MM |
|
Bore
x Stroke:72mm x 60mm |
Displacement:
260ml |
|
Rated
Power Speed:10.5KW/
7000r/min |
Engine
type:water-cool |
|
Lubricating
oil:15W/40 |
Max
Torque:17.6N.m/5500r/min |
|
Compressing
Ratio:10.0:1 |
Ignition
mode:CDI |
|
Spark
plug :DPR7E-9 NGK |
Starting
System:Electric |
|
Cooling
System:Water cooled |
|
TRANSMISSION
|
|
Transmission
type:CVT Shaft Drive
|
|
Gearshift
Mode:Automatic with reverse |
|
|
Climbing
Ability:>=15degree |
|
|
Max
Speed:75km/h |
Brake
system(front/rear):Drum/disc |
|
|
FUEL:
Unleaded Gasoline
|
|
Fuel
tank capacity:7.5L |
Available
colors:Red yellow blue dark
green |
|
|
|
|
40' Container Capacity:36 |
