| POWER TRAIN |
| Engine |
124cc air cooled, 4 stroke, single cylinder engine |
| Bore/Stroke |
54mm/54.2mm (2.12in/2.13in) |
| Compression Ratio |
9.2:1 |
| Horsepower |
7.5hp@8000rpm |
| Torque |
8.25nm@6000rpm (6.09 Lb-ft) |
| Fuel System |
Carbureted |
| Lubrication |
Wet Sump |
| Ignition |
CDI |
| Transmission |
3 speed semi automatic + (Reverse) |
| Gear Ratio |
3 gear shift |
| Final Drive |
82 link chain |
| DIMENSIONS |
| Overall Length |
1549mm (61in) |
| Overall Width |
863mm (34in) |
| Overall Height |
965mm (38in) |
| Seat height |
698.5mm (27.5in) |
| Ground Clearance |
109mm (4.3in) |
| Wheelbase |
944mm (37.2in) |
| Dry Weight |
139.70kg (308lbs) |
| CHASSIS |
| Suspension Front |
Dual control arm, Coil over shock, Oil Dampened |
| Front Travel |
64mm (2.52in) |
| Suspension Rear |
Central Drive Unit, Spring over shock, Oil Dampened |
| Rear Travel |
49.5mm (1.95in) |
| Brakes Front |
Front drum rear disc |
| Brakes Rear |
Single Disc |
| Tires Front |
19.0 x 7.0 x r8.0 |
| Tires Rear |
19.0 x 9.5 x r8.0 |
| OTHER |
| Fuel Tank Capacity |
6.6L (1.7Gal) |
| Color |
Blue, Red, Green, Black |
| Battery Type |
12V/7Ah |
|
|
