HENSIM
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| POWER TRAIN | |
| Engine | 107cc air cooling, 4 stroke, single cylinder engine |
| Bore/Stroke | 52.4mm/49.5mm (2.06in/1.94) |
| Compression Ratio | 9.1:1 |
| Horsepower | 7.4hp@8000rpm |
| Torque | 6.50nm@6000rpm (4.8Lb-ft) |
| Fuel System | Carbureted |
| Lubrication | Wet Sump |
| Ignition | CDI |
| Transmission | Chain Drive, No Reverse |
| Gear Ratio | 4 gears |
| Final Drive | N/A |
| DIMENSIONS | |
| Overall Length | 1524mm (60.0in) |
| Overall Width | 685mm (27.0in) |
| Overall Height | 977mm (38.5in) |
| Seat height | 749mm (29.5in) |
| Ground Clearance | 299mm (11.8in) |
| Wheelbase | 1049mm (41.3in) |
| Dry Weight | 75.01kg (165.38lbs) |
| CHASSIS | |
| Suspension Front | Hydraulic pressure, sleeve |
| Front Travel | 105mm (4.13inch) |
| Suspension Rear | Swing arm, hydraulic spring |
| Rear Travel | 20mm (0.79inch) |
| Brakes Front | Disk |
| Brakes Rear | Disk |
| Tires Front | 2.5-14 |
| Tires Rear | 3.0-12 |
| OTHER | |
| Fuel Tank Capacity | 3.3L, (0.87Gal) |
| Color | Blue, Red, Green, Black |
| Battery Type | No battery |
| Skid Plate |
|
