Model Number:

 ATV-3125XR8-U

Engine Type:

 125CC Single cylinder, 4-stroke, air-cooled

Max Torque:

 7.0N.m/5500r/min (N.m/r/min)

Max Horsepower:

 5.0kW/7500r/min

Bore Stroke:

 52.4x49.5mm

Ignition:

 CDI

Starting System:

 Electric

Battery:

 12V, 5Ah

Clutch:

 Fully-Automatic

Transmission:

 Chain, Foot

Brakes Front/Rear:

 Hub/hydraulic disc

Tires Front/Rear:

 19 x 7 - 8 / 18 x 9.5 - 8

Fuel Capacity/Oil Type:

 90#/0.9L

Weight:

 G.W./N.W :118KG /98KG

Wheelbase (Front/Rear):

 855mm

Dimensions:

 1,465 x 920x 925mm

Height to Seat:

 620mm

Min. Ground Clearance:

 140mm
