Terminator 300 4x4

4 Wheel drive ATV

TERMINATOR 300

Vehicle specification
Overall Vehicle Size (L x W x H)    83x46x 50 in
Ground Clearance (inch)     7.2 in
Wheelbase (inch)    51 in
Weight with full equipment              618 lbs
Front / Rear Brakes    Two sides hydraulic disc
Parking Brake    Front / Rear hand brake,Foot brake
Front Tires    AT24X8-12
Rear Tires    AT24X11-10
Front Suspension    McPherson independent suspension
Rear Suspension    Socket centering structure
Fuel Capacity    3.8 gallons
Engine specification
Engine model    LH173MN
Engine Type    Carburetor, 4 Stroke, Single Cylinder, SOHC, Water Cooling
Bore & stroke    2.85*2.63 in
Volumetric Compression Ratio    10.3:1
Displacement    257cc
Drive System Type    2WD or 4WD
Ignition type    T.C.I
Start type    Electric
Maximum  power (Kw /r/min)    22 HP @ 6500 RPM
Maximum Torque (Nm /r/min)    14.8 lb-ft @ 5500 RPM

Terminator 300 4x4 4 Wheel drive ATV Black

Mefast Wholesale

Terminator 300 4x4 4 Wheel drive ATV Right side view camo

Terminator 300 4x4 4 Wheel drive ATV Right front view camo

Terminator 300 4x4 4 Wheel drive ATV Front view camo

Terminator 300 4x4 4 Wheel drive ATV Left front view camo

Terminator 300 4x4 4 Wheel drive ATV Left view camo

Terminator 300 4x4 4 Wheel drive ATV Left rear view

Terminator 300 4x4 4 Wheel drive ATV Right rear view camo

Terminator 300 4x4 4 Wheel drive ATV Rear view camo

Terminator 300 4x4 4 Wheel drive ATV Left side view blue

Terminator 300 4x4 4 Wheel drive ATV Red
