| Model Name |
HY150T-5 |
| Engine Displacement (cc) |
149.6 |
| Engine Style |
Single cylinder, 4-stroke, air-cooled |
| Engine Type |
157QMJ |
| Bore*Stroke (mm*mm) |
57.4*57.8 |
| Compression Rate |
9.2:1 |
| Ignition |
CDI |
| Transmission |
CVT |
| Net Weight (kg) |
113 |
| Dimensions(mm) |
1983×683×1100 |
| Wheelbase |
1983×683×1100 |
| Tire Size(inch) |
130/60-13 |
| Fuel Capacity(L) |
7 |
| Idling Speed |
1600±100 |
| Max loading weight(kg) |
155 |
| Max Speed(km/h) |
85 |
| Max power(kw/r/min) |
7.0/7500 |
| Max torque(n.m/r/min) |
9.0/6000 |
| Brake Operations(F/R) |
Hand / Hand |
| Brake Mode(F/R) |
Disk / Drum or disk |
| Economic Fuel Consumption
(L/KM) |
≤2.9/100 |
| Starting System |
Electric / Kick |
| Battery size(V/AH) |
12V/7Ah |
| QTY/40HQ/20GP |
72/24 |
|
|
