ENGINE

PISTON DISPLACEMENT

200CC

ENGINE MODEL

6CGQX.200DB1

ENGINE TYPE

4-strokes, air-cooled

CYLINDER ARRANGEMENT

Single cylinder

COMPRESION RATIO

9.0:1

BORE x STROKE (MM)

63mm x 62mm

MAX POWER (KW/RPM)

11KW / 7500RPM

MAX TORQUE (N.M/RPM)

13.5N.m / 6000RPM

IGNITION

CDI

LUBRICATION

Pressure splash

BATTERY

N/A

STARTING

Kick Start

FUEL TYPE

Unleaded Gasoline 89 Octane

FUEL TANK CAPACITY

(US GALLONS) 1.50 Gallons

DRIVE TRAIN

CLUTCH/GEARBOX

Manual/5-speed

DRIVE TYPE

Chain

REVERSE GEAR (y/n)

N/A

SUSPENSION/BRAKES

F/R TIRE SIZE

Fr: 2.75 - 21        Rr: 4.10 - 18

F/R BRAKE

Fr: disk               Rr: disk

FRONT SUSPENSION

Dual Telescoping

REAR SUSPENSION

Swing Arm, Mono Shock

OVERALL SIZE (LxWxH/in)

94” x 35 ” x 47”

MIN.GROUND CLEARANCE

11”

SEAT HEIGHT

33“

WHEEL BASE (in)

54”
