HENSIM

 400cc 4WD Utility ATV

HS-400U

These quality products are availble at your local MacroMover Store now

POWER TRAIN
Engine 387.4cc oil and air cooled, 4 stroke, single cylinder yamaha engine
Bore/Stroke 83mm/71.6mm (3.26in/2.81in)
Compression Ratio 8.7:1
Horsepower 21.47hp@8000rpm
Torque 26.03nm@6000rpm (19.2Lb-ft)
Fuel System Carbureted
Lubrication Wet Sump
Ignition DC-CDI, Electric and Recoil Starter
Transmission Shaft Drive Semi Auto + (Reverse) selectable 2x4 or 4x4 wd
Gear Ratio 5-speed/1-Reverse
Final Drive N/A
DIMENSIONS
Overall Length 2098mm (82.6in)
Overall Width 1125mm (44.3in)
Overall Height 1173mm (46.2in)
Seat height 858mm (33.8in)
Ground Clearance 210mm (8.3in)
Wheelbase 1239mm (48.8in)
Dry Weight 265.98kg (586.4lbs)
CHASSIS
Suspension Front Double A-arm Coil over shock
Front Travel N/A
Suspension Rear Central unit spring over shock absorber
Rear Travel N/A
Brakes Front Dual Disc
Brakes Rear Single Drum
Tires Front 25 x 8 x r12
Tires Rear 25 x 10 x r12
OTHER
Fuel Tank Capacity 14L (3.7Gal)
Color
Battery Type 12V/20Ah








Right side view

Front left view

Right front view

Front view

Left side view
